真空检漏设备 氦质谱检漏仪 ZXL-830 无损检测仪器 真空炉检漏

返回列表
Image description

Product Introduction

●Full LCD touch color screen, easy to operateStandard desktop chassis with beautiful and practical appearance
●High pressure resistance of leak detection portWide detection range, spanning 10 magnitudes
● Detection values can be stored
●One click reset of leak detection status

●Chinese and English menu interfaceThe entire machine has reached the international advanced level

Main configuration

1.Imported molecular pump

2.Imported mechanical pump

3.Built in standard leak hole

4.American AD amplifier

5.Mass spectrometry dedicated module

6.Delta LCD touch color screen

Specification


1. Minimum detectable leakage rate: 3×10-13Pa ·m³/s

2. Leakage rate display range: 1×10⁻ ¹- 1×10-13Pa ·m³/s

3. Starting time: ≤ 3min

4. Response time: ≤ 0.5s

5. Maximum pressure at the leak detection port: 1500Pa

6. Mechanical pump pumping speed: 8m³/h （12 m³/h）

7. Power requirements: 220V, 50Hz, single-phase, 10A

8. Working environment: 5-35 ℃

9. Relative humidity: ≤ 80%

10. Boundary dimension:550(W)×450(D)×880(H)

11. Weight: 62kg
